| Driving Type | 6×4 |
| Displacement criterion | EUR II |
| Gross vehicle weight | 26,000 kg |
| Maximum loading capacity | 15,000 kg |
| Engine Type | Diesel, 4-stroke, direct injection engine |
| Engine model | Steyr WD12.336 |
| Engine | 6-cylinder in-line with water cooling, turbocharged & intercooled |
| Maximum output according to DIN | 247 KW at 2,200 rpm 336HP |
| Displacement | 11.596L |
| Min. fuel consumption | ≤198 g/kwh |
| Transmission Model | Fuller RT-11509CV |
| Operating type | Manual shift with hydraulic assistant |
| Transmission Type | With constant-mesh-gear braker |
| Constant-mesh | 8 forward & 1 reverse 8 speed shift |
| Front axle model | Steyr 6.5T |
| Rear axles model | Steyr 13T |
| Steering system model | ZF8098, (Germany ZF ,made in China) |
| Electrics Operating voltage | 24V, negative grounded |
| Driver’s cab size | 2,030*2,490*2,623 mm |
| Wheelbase | 3,600 +1,350 mm |
| Cargo body size | 19.3CBM |
| Maximum driving speed | 92 km/h |
| Fuel tank capacity | 380 L |
